GMKtec NucBox M2

GMKtecMini PC reference

GMKtec NucBox M2

GMKtec NucBox M2 combines Intel Core i7-11390H with integrated Intel Iris Xe (dual-channel memory) for office multitasking, development and media work. Gaming and GPU-accelerated applications depend on their settings and driver support; the graphics specification alone is not a measured performance result. Replaceable SO-DIMM memory gives it a path for later RAM upgrades.

Processor
Intel Core i7-11390H
Graphics
Intel Iris Xe (dual-channel memory)
Memory
Not included
Storage
Not included
Configuration being comparedBarebone · RAM & SSD not includedNew
US stores · USD

Prices across stores

MiniPC.guru compares retailer listings. Purchases are completed on the retailer’s website.

View price history
RetailerAvailabilityListed priceLast checkedRetailer website
In stock$269View at GMKtec

Availability reflects the latest store check. Shipping, tax, coupons and checkout totals are not included; confirm them at the store.

Specifications

Processor, graphics and installed memory/storage describe the selected configuration. Expansion limits and connectivity describe the model; optional hardware is identified separately. References are collected in About this data below.

Processor
Intel Core i7-11390H
Graphics
Intel Iris Xe (dual-channel memory)
Memory
Not included
Storage
Not included
Ports & displays
3 × USB-A 3.2, 1 × USB-A 2.0; 2 × HDMI (4K/60Hz); USB-C with DisplayPort and data; 1 × 2.5GbE; 3.5mm CTIA audio and DC input. USB-C data rate is not specified in the current US port diagram.
Ethernet, Wi-Fi & Bluetooth
1 × 2.5GbE; Wi-Fi 6; Bluetooth 5.2.
RAM & storage upgrades
2 × DDR4-3200 SO-DIMM slots, up to 64GB. One M.2 2280 PCIe NVMe SSD slot up to 2TB plus one M.2 2242 SATA SSD slot up to 2TB.
Power supply & power limits
DC input: 20V, 5A / 100W. Supply rating, not measured wall-power consumption.
Dimensions & weight
Manufacturer states net weight of 361g; current US diagrams do not provide complete chassis dimensions.

What owners say

Four reviewers had the NucBox M2 with the Core i7-11390H, a 2021 laptop chip in a small metal box, and they agree it is quiet in ordinary use and not for gaming. At idle it is mostly inaudible; under load the fan spins up quickly and noticeably, with an odd whoosh close up that is barely noticeable from a normal distance. The processor sits around 60 °C in everyday use. Identical-looking ports run at different speeds: the two front USB-A ports are 10 Gbps, while at the back one is 5 Gbps and one only USB 2.0, and the single USB-C port is 5 Gbps. Four small screws under the feet, easy to lose, open it to the memory slots, the M.2 2280 drive and a free 2242 slot; the base looks built for a 2.5-inch drive, but there is no SATA connector. The factory SSD varies from unit to unit. Emulation is its strength: almost every system up to the Wii U ran at full speed in Batocera, and PS3 reached about 90% with glitches. DaVinci Resolve struggled with 1440p footage. GMKtec distributes its drivers through a Google Drive link, which one reviewer calls untrustworthy, and first-boot updates took over twenty minutes. There is only one network port.

For whom
A quiet desktop, conference-room PC or emulation box, bought as a barebone.
Not for
Gaming, video editing above 1080p, and firewall builds — it has a single network port.

Our own summary of 5 published sources, reviewed Sep 23, 2026. We have not tested this Mini PC ourselves; the sources are listed under About this data.

Performance

No reviewed results yetpoints

Same Procyon Office Productivity version, application versions and power profile.

Price history

GMKtec NucBox M2 · Barebone · RAM & SSD not included

Loading checks…

New condition · US stores · USD · Selected configuration only. Prices exclude shipping and tax. Each price stays on the chart until that listing's next check, for at most 36 hours, the same window the store prices use. Out-of-stock, failed and missing checks leave gaps.

About this data6 references

Specs and any benchmark results come from the sources below. We haven't tested this Mini PC ourselves.

Notes

  • dimensions: Confirm full chassis dimensions using a current manufacturer technical sheet; current US diagrams state weight only.

Sources

  1. GMKtec NucBox M2 — manufacturer specifications and port diagrams ↗
    • Manufacturer / specification source
    • Ports & displays · Reviewed Sep 12, 2026
    • Ethernet, Wi-Fi & Bluetooth · Reviewed Sep 12, 2026
    • RAM & storage upgrades · Reviewed Sep 12, 2026
    • Power supply & power limits · Reviewed Sep 12, 2026
    • Dimensions & weight · Reviewed Sep 12, 2026
    • Owner review source · Reviewed Sep 23, 2026
  2. Selected configuration ↗
    • Selected configuration
  3. GMKtec NucBox M2 Mini PC review ↗
    • Owner review source · Reviewed Sep 23, 2026
  4. Mini-PC GMKtec Nucbox M2 im Test: Viel Leistung für 347 Euro ↗
    • Owner review source · Reviewed Sep 23, 2026
  5. GMKTEC NucBox M2 Review [i7-11390H] ↗
    • Owner review source · Reviewed Sep 23, 2026
  6. Intel i7にIris Xeグラフィックで11 Pro搭載のミニPC!GMKtec『NucBox M2』レビュー ↗
    • Owner review source · Reviewed Sep 23, 2026
